0.7m-2.0m Wire Mesh Fencing Grassland Horse And Cattle Fencing With Y T Post

Hot Dipped Galvanized Grassland Cattle Horse Cow Animal Farm Wire Mesh Fence with Y T Post

grassland cattle horse fence is a fence found in the livestock farming. The deer fence is widely used in the grassland areas for purposes of protecting ecological balance and preventing landslides. It looks very attractive, it is sturdy, durable and low priced. The grassland cattle horse fence is normally made out of hot-dip galvanized steel wires, whose zinc coating weight is usually 60g-100g/m2. But in wet areas, there is a relatively high requirement for the zinc coating weight, namely about 230g/m2. Recently cold galvanized steel wires are also used to produce deer fences in Africa.

Horizontal wires, or warp wires of the grassland cattle horse fence panel, feature their tensile resistance 80kgs to 90kgs to increase their impact resistance. Meanwhile vertical wires, or weft wires of the deer fence mesh panel, are mild steel wires with tensile resistance 40kgs to 50kgs. Vertical wires are wrapped around horizontal wires, and in terms of the wrapping process, the edge wire should be wrapped at least 2.5 laps, whereas the inner wire should be wrapped at least 5 laps (In the course of wrapping, the mechanical pressure 2Tons to 3Tons should be applied to prevent vertical wires from sliding).

Hot Dipped Galvanized Grassland Cattle Horse Cow Animal Farm Wire Mesh Fence with Y T Post

Hot Dipped Galvanized Grassland Cattle Horse Cow Animal Farm Wire Mesh Fence with Y T Post

0.7m Wire Mesh Fencing

2.0m Wire Mesh Fencing

Grassland Horse And Cattle Fencing

0.7m-2.0m Wire Mesh Fencing Grassland Horse And Cattle Fencing With Y T Post Images
